Fishing trolley

Customer name: RICK

Country: United Kingdom

Industry: Fishing trolley

The customer is a British company that specializes in manufacturing fishing equipment. This time they need the motor to be used on their newly designed trolley.

The product lithium-powered electric wheel kit that uses the motor is designed to convert the seat box into a lithium-powered 4-wheel trolley. It is composed of front and rear modules. The rear module mounts two height-adjustable handles and wheels to the rear of the box, while the front module mounts the electric wheel kit to the front of the pedal. It takes about one minute to convert the seat box into a 4-wheel electric trolley. The power unit is fully customized and does not use any parts from the golf industry. The 60:1 gear ratio provides tremendous torque, which when combined with large high-grip wheels ensures that the trolley can handle any load that the angler wants to move easily. The high ground clearance also ensures that the system will not be grounded on rough ground.

What they need：High quality and high torque 80mm 12V brushless RV geared motor

DIFFICULTY

Difficulty: In the communication with the customer, the customer put forward several problems that need to be solved.

1. The customer's voltage is very low, the power is high, and the torque required is very large.

2. It is thought that the shaft connecting the gearbox to the customer is very long, and the left and right lengths are different. How to fix it on the gearbox is a problem.

3. Customers hope that our motor can be connected to their handle and can be directly operated by the potentiometer, how to wire it.

SOLUTION

1. It is recommended to customers to use 80mm brushless motors with strong magnetic materials, which can reach the power required by customers at a lower voltage.

2. Add a shaft sleeve on the basis of the original gearbox and fix it with shaft sheaths at both ends.

3. Plan a complete circuit diagram for the customer, and they are responsible for the design of the wire, which can solve their handle operation problem.
