The 36V/48VDC planetary geared motors are developed and designed for high-precision and high-torque equipment, with a voltage of 1KW, a maximum allowable radial force of ≤500N, and a maximum allowable axial force of ≤130N.
The minimum speed value is 200rpm, 100rpm and 50rpm. The rated allowable load is 80N.m. Reduction ratios range from 1:4 to 1:216. The length of the gearbox is mainly 80mm, 94mm and 108mm. It is suitable for lifting equipment, fire-fighting equipment, AGV logistics and transportation equipment, robots and other scenarios.
In addition, you have a number of customization options.For details, please refer to the Customization page.
The 86mm brushless DC planetary geared motor is equipped with 24V, 36V and 48V brushless DC motors, which has the unique advantages of high torque, high precision, low speed and low noise. The rated torque is between 14.33N.m and 80.00N.m.
The reduction ratio of the reducer is from 1:4 to 1:216, and the larger the speed ratio, the lower the speed and the greater the torque.
High efficiency, long life, large load, can be applied to all kinds of high-precision, high-load, long-life, protective application equipment.
Forward rotation and reverse rotation can be selected, CW/CCW
Provide a number of customized options: shaft, reducer length, motor length, voltage, power supply, output line, lead wire, label stamp, etc.
| Model | Voltage | No-load | Rated Load | Stall | Body Length | ||||||
| Speed | Current | Power | Speed | Torque | Current | Torque | Current | ||||
| V | rpm | A | W | rpm | Nm | A | Nm | A | L:mm | ||
| BG-86BLDC-4830S-2 | 48 | 4000 | 4.07 | 1250 | 3000 | 3.98 | 32.6 | 11.94 | 97.66 | 130 | |
| BG-86BLDC-31030S | 310 | 4000 | 0.40 | 785 | 3000 | 2.50 | 3.2 | 7.50 | 9.50 | 130 | |
| Model | Reduction ratio | 1：X | 1：4 | 1：10 | 1：24 | 1：36 | 1：64 | 1：96 | 1：144 | 1：216 | |
| Gearbox length | L：mm | 80 | 94 | 108 | |||||||
| BG-86BLDC-4830S-2 | NO-load speed | rpm | 1000 | 400 | 167 | 111 | 63 | 42 | 28 | 19 | |
| Rated speed | rpm | 750 | 300 | 125 | 83 | 47 | 31 | 21 | 14 | ||
| Rated torque | N.m | 14.33 | 32.23 | 77.36 | 80.00 | 80.00 | 80.00 | 80.00 | 80.00 | ||
As shown in the figure above, mixer trucks, fire-fighting equipment, AGV trolleys, and lifting equipment are common applications of 48VDC Planetary Geared Motor, in addition to robotics, medical equipment, electric vehicles, automated handling equipment, smart homes, blowers, solar systems, etc. are all application fields of 48VDC planetary gearboxes, if you have any needs in these aspects, please contact us in time.
