Name: Andreas
Industry: Cleaning Manufacturer
Cooperation time: 2023
An international cleaning equipment brand customer (based in Germany) planned to upgrade its flagship product, a commercial walk-behind floor cleaner. The target market is airports, hospitals, shopping malls and other places, which require comprehensive improvement in operation stability, cleaning efficiency, quiet effect and protection level, and want to optimize the performance of brush drive and water suction system while maintaining a compact structure.
1. The brush motor has a short life and frequent overheating
2. The noise of the suction motor is high, and the customer feedback experience is poor
3. The structure of the whole machine is compact, and it is difficult to install multiple sets of motor systems
4. Lack of low-speed torque, stable performance of the walking drive scheme
5. The drainage pump is often blocked, the sewage discharge efficiency is low, and the after-sales rate is high
Based on customer structural drawings and application scenarios, BG Motor provides customized motor integration solutions:
Model: AC-9550 series high speed general AC motor
Parameter: Rated voltage 220V / power 350W / speed 8000RPM
Features: high wear-resistant carbon brush, high temperature enameled wire, long life bearing
Advantages: 4 hours of continuous work without heat decay, efficient cleaning of heavily polluted areas
Model: BG-VHC1050 series vacuum motor
Parameters: Power 1050W / Rated speed 24,000RPM / Vacuum ≥ 22KPa
Features: High suction, low noise (≤ 58dB), double air duct design
Advantages: Ensure that the ground dries quickly, suitable for low-noise places such as hospitals and airports
Structure: waterproof and dustproof package, IP54 protection level, adapt to humid environment
Model: BG-370PL planetary geared DC motor
Parameter: 24V DC / Torque ≥ 10Nm / Output Speed: 120RPM
Features: slow speed and high torque, support forward and reverse rotation
Advantage: Smoothly advance the equipment and solve the problem of slippage and shock vibration
Model: BG-MP28 DC motor for micro pump
Parameter: 24V / Power 35W / Flow ≥ 6L/min / Head ≥ 1.8m
Features: Anti-tangle impeller design, strong anti-impurity performance
Benefits: Solve blowdown blockage, extend pump life, and reduce maintenance frequency
1. The operating noise of the whole machine is reduced by 20%
2. The water absorption efficiency is increased by 25%, and the drying time of the ground is shortened after cleaning
3. The stability of the drive system is improved, and the implementation is smooth and jitter-free
The annual after-sales failure rate has decreased by 42%, and customer satisfaction has been significantly improved
